Adopting a 7-inch full touch screen operation panel, the icon of the operation button is visualized, making it convenient for users to operate;

With online plate making function, users can achieve plate making of sewing patterns through simple operations;

The pattern editing function allows for process changes such as starting point offset, rotation, mirroring, and scaling of the prepared pattern;

Supports two automatic template recognition methods: barcode scanner and non-contact sensor;

The spindle motor adopts advanced servo control technology, which makes the machine respond faster and greatly improves sewing efficiency;

For different format models, the system supports three driving modes: stepper motor, stepper closed-loop motor, and servo motor;

Intelligent motion control algorithm, high-quality implementation of special sewing processes such as curve sewing, encrypted sewing, corner sewing, overlap sewing, etc;

The system supports automatic recognition of starting points, stroke positions for up and down point numbers, line break detection, automatic thread cutting, and other functions, improving machine automation and saving manpower;

Strong scalability and flexibility, with a total of 32 input and output ports. Users can customize the functions of the expansion ports and design to achieve their own unique machine functions;

The control box circuit is highly integrated, the box is lightweight, and the system installation is convenient and reliable.

Special features:

Supporting the synchronization of needle bar and rotary shuttle gantry, which can save mechanical costs, improve sewing speed, and reduce machine head vibration;

Support the machine head lifting and rotating functions, solve traditional mechanical defects, make sewing stitches more exquisite, and meet special sewing needs; The system supports the expansion of laser cutting function, which can cut and shape the fabric during or after the sewing process; Support for stepper motor thread cutting function, making thread cutting more stable and efficient;

Support the motor presser foot function, which can increase or decrease the presser foot height according to the thickness of the fabric, meeting the sewing requirements of different thicknesses of fabrics; The system can add automatic loading and unloading functions according to customer needs, making the template machine more automated.
